Descripción

CARACTERÍSTICAS DE HARDWARE

Procesador
Qualcomm 560MHz CPU, MIPS 74Kc

Memoria
64MB DDR2 RAM,8MB Flash

Interface
1 10/100Mbps Shielded Ethernet Port (LAN/POE)1 Reset Button

Fuente de Alimentación
Passive Power over Ethernet via LAN (+4,5pins; -7,8pins)Voltage range: 16-27VDC

Dimensiones (W X D X H)
350 x 255 x 207 mm (13.8 x 10.0 x 8.1 in.)

Ganancia de Antena
23dBi

Cobertura de Antena
7°(Azimuth), 10°(Elevation)

Protección
15KV ESD Protection6KV Lightning Protection

Cercado
Material: Outdoor PC stabilized plasticWeatherproof: IP65 water and dust proof design

CARACTERÍSTICAS INALÁMBRICAS

Estándares Inalámbricos
IEEE 802.11a/n

Protocolo Propietario
TDMA Mode (with Pharos MAXtream enabled)

Velocidades Inalámbricas
Up to 150Mbps (40MHz,Dynamic)Up to 72.2Mbps (20MHz,Dynamic)Up to 36.1Mbps (10MHz,Dynamic)Up to 18.05Mbps (5MHz,Dynamic)

Frecuencia
5.15~5.85GHz

Potencia de Transmision
Max. 23dBm (Adjustable power by 1dBm)

CARACTERÍSTICAS DE SOFTWARE

IPv6
Yes

Configuracion De Red
WAN: Static/Dynamic/PPPoE/L2TP/PPTPLAN: Static/Dynamic/DHCPForwarding: ALG/UPnP/Virtual Server/Port TriggerSecurity: SPI Firewall/ Ping Forbidden/DoS ProtectionAccess ControlStatic RoutingBandwidth ControlIP & MAC Binding

Configuraciones Inalámbricas
Pharos MAXtream TDMA TechnologySelectable Channel Width: 5/10/20/40MHzAuto Channel SelectionTransmit Power ControlDynamic Frequency Selection(DFS)WDS Enable/DisableSecurity: WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) Encryption,64/128/152-bit WEP EncryptionSSID Broadcast Enable/DisableMulti-SSID with VLAN Tagging(AP Mode only)Distance/ACK Timeout SettingWireless MAC Address FilterWireless Advanced:Beacon Interval/RTS Threshold/Fragmentation Threshold/DTIM Interval/AP Isolation/Short GI/Wi-Fi Multimedia

Administración
Discovery and Remote Management via Pharos Control applicationHTTP/HTTPS Web-based managementSystem logSNMP Agent(v2c)Ping Watch DogDynamic DDNSSSH Server

Herramientas de sistema
Indicators:Signal Strength/Noise/Transmit CCQ/CPU/MemoryMonitors: Throughput/Stations/Interfaces/ARP/Routes/WAN/DHCPSpectrum AnalyzerSpeed TestPingTraceroute

Optimizaciones a Nivel de Sistema
Optimized IGMP Snooping/Proxy for multicast applicationsHardware watch dog

POE ADAPTER FEATURES

Dimensions(W x D x H)
85.8×43.9×29.7 mm

Interfaces
1 AC Jack with Earth Ground1 10/100Mbps Shielded Ethernet Port (Power + Data)1 10/100Mbps Shielded Ethernet Port (Data)

Botón
Remote Reset Button

Power Status LEDs
Green

Input
100-240VAC, 50/60Hz

Output
24VDC, 0.6A Max+4, 5pins; -7, 8pins. (Support up to 60m Power over Ethernet)

Eficiencia
>84.29%

Certifications
CE/FCC/UL/IC/GS/PSB/C-tick/SAA/S-Mark/KC-mark

OTROS

Certificacion
CE, FCC, RoHS, IP65

Contenidos del Paquete
Outdoor Wireless CPE24V 0.5A Passive PoE AdapterPole Mounting StrapsAC Power CordInstallation Guide

Requisitos del Sistema
Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 10, Windows 8, Windows 7, MAC OS, NetWare, UNIX or Linux.Note: We recommend you to use one of following Web browsers for an improved user experience: Google Chrome, Safari, and Firefox. IE browsers are not recommended.

Ambiente
Operating Temperature: -40℃~70℃ (-40℉~158℉)Storage Temperature: -40℃~70℃ (-40℉~158℉)Operating Humidity: 10%~90% non-condensingStorage Humidity: 5%~95% non-condensing
